| Article number: |
EWP226866 |
| Availability: |
Out of stock |
| Delivery time: |
3 to 4 weeks |
Residual current circuit breaker 4P 300mA Type A 16A curve C
Residual current circuit breaker 300mA type A and automatic current switch 16A curve C in 1 device.
- Total number of poles: 4
- Number of protected poles: 3
- Rated voltage: 400 V
- Rated current: 16 A
- Rated fault current: 0.3 A (300mA)
- Leakage current type: A
- Nominal breaking capacity according to EN 61009: 10 kA
- Rated breaking capacity IEC 60947-2: 6 kA
- Rated short-circuit breaking capacity Icn according to EN 61009-1: 6 kA
- Surge voltage resistance: 0.25 kA
- Voltage type: AC Frequency: 50 Hz Tripping characteristic: B
- Co-switching neutral: Yes
- With locking device: No
- Width in module units: 5
- Connectable conductor cross-section single-wire: 0.75 - 16 mm²
- Connectable conductor cross-section multi-wire: 0.75 - 10 mm²
CE certificate
